The ZMPT101B AC Single Phase Voltage Sensor Module is used to measure AC (alternating current) voltage in single-phase systems. It’s commonly utilized in various applications where monitoring and control of AC voltage levels are necessary. This is the best for the purpose of the DIY project, where we need to measure the accurate AC voltage with a voltage transformer.
This is an ideal choice to measure the AC voltage using Arduino/ESP8266/Raspberry Pi like an open-source platform. In many electrical projects, an engineer directly deals with measurements with a few basic requirements like High galvanic isolation, Wide Range, High accuracy, and Good Consistency.
Onboard precision miniature voltage transformer, The active phase AC output voltage transformer module. Onboard precision op-amp circuit, the signal sampling and appropriate compensation for precise functions. Modules can be measured within 250V AC voltage, and the corresponding analogue output can be adjusted. It is brand new, good quality high performance.
This module is designed to specifically measure the voltage in single-phase AC circuits, which are common in household electrical systems. The ZMPT101B is usually calibrated to work within a certain voltage range. For instance, a common version may be calibrated for voltages within 0-250V AC. This sensor module finds applications in various fields including power supplies, industrial automation, and smart home systems. Its compatibility with different voltage levels and frequencies makes it suitable for a wide array of projects.
It provides an output signal that is proportional to the measured voltage. This output can be an analogue voltage signal that corresponds to the AC voltage level. The module typically comes with connectors or pins for easy integration into electronic circuits. It can be connected to microcontrollers, ADCs (Analog-to-Digital Converters), or other measurement devices.
The ZMPT101B is commonly used in applications like power monitoring systems, energy management systems, smart home automation, and various industrial automation projects.
Specifications
Operating Voltage: 250V
Output Signal: 0-5V
Operating Temperature : 40ºC ~ + 70ºC
Voltage Transformer: On-board Precision Micro Voltage Transformer
Operational amplifier circuit: high-precision on-board amplifier circuit, the signal to do the exact sampling and appropriate compensation and other functions
Mode voltage output: the module can measure AC voltage within 250V, and the corresponding output mode can be adjusted.
Features
Accurate Voltage Detection-
The ZMPT101B AC Voltage Sensor Module is a precise instrument for measuring single-phase AC voltage. Its high-quality components and advanced circuitry ensure accurate readings, making it an indispensable tool for electrical monitoring and control systems.
Wide Range of Applications-
Designed for versatility, this sensor module finds applications in various fields including power supplies, industrial automation, and smart home systems. Its compatibility with different voltage levels and frequencies makes it suitable for a wide array of projects.
User-Friendly Integration-
Featuring a compact design and straightforward interface, the ZMPT101B module is easy to install and integrate into existing systems. Whether you’re a seasoned professional or a DIY enthusiast, you’ll appreciate the simplicity and efficiency it brings to your projects.
When working with AC voltage, it’s crucial to observe proper safety precautions. This includes ensuring that the module is correctly connected and that appropriate safety measures are in place to prevent electric shock or damage to equipment.
Package Included
1 x Voltage Sensor Module ZMPT101B AC Single Phase Voltage Sensor Module
