The 3.5-inch Touchscreen matches with the Raspberry Pi 4 Case with TFT, better display, and supports the Raspbian Buster System. The screen board design with Power Pin support connects with a fan. Come with a mini cooling fan and heat sink to make sure your Pi works stable and achieves the best heat dissipation, no need to worry about heat dissipation.
The display resolution is 480*320, The Raspberry Pi display supports 125MHz SPI signal input, and it can display stable without flicker. When it works with Raspberry Pi, the refresh rate is about 60FPS, which is enough to play the video and game. Protecting your screen and Pi, the split design is easier to install and has good ventilation, with a white nylon column to help the screen maintain balance.
The hole of the Raspberry Pi 4 Case with TFT perfectly coincides with the interface of the Raspberry Pi. Better protect the Raspberry Pi and display. The heat sinks improve heat dissipation more effectively, which improves user safety. Rubber feet play the role of anti-slip, to prevent the device from sliding on the table, to make your project go smoothly.
The back of the display is designed with screw holes for installing the fan, and a power interface to supply power to the fan. The fan can be compatible with the display, Solving the problem that the fan and the display could not work with the Raspberry Pi at the same time, improving heat dissipation more effectively. Cooling the Raspberry Pi while the display is working, to increase usage time.
The Raspberry Pi 4 Case with TFT is custom-designed to fit the Raspberry Pi 4, ensuring precise alignment with the board’s ports, connectors, and components. The Raspberry Pi 4 Case with TFT includes a TFT screen, with a size of 3.5 inches, providing a visual interface for the Raspberry Pi. The display’s resolution is 480*320, and it is designed to provide clear and detailed visuals for various applications.
Specifications
Screen Size
3.5inch
LCD Type
TFT
Module Interface
SPI (supports up to 125MHz SPI input)
Resolution
320*480 (Pixel)
Touch Screen Controller
XPT2046
LCD Driver IC
ILI9486
Backlight
LED
Power Consumption
0.16A*5V
Working Temperature
-20~60℃
Active Area
48.96×73.44(mm)
Features
Integrated Display for Enhanced Functionality-
The Raspberry Pi 4 Case with TFT Display offers a seamless combination of protection and functionality. The integrated display provides an additional visual interface for your projects, making it ideal for various applications.
Durable and Impact-Resistant-
Raspberry Pi 4 Case with TFT is crafted from high-quality materials, this case ensures robust protection for your Raspberry Pi 4. Raspberry Pi 4 Case with TFT shields against dust, minor impacts, and electromagnetic interference, safeguarding your mini-computer’s longevity and performance.
Easy Installation and Accessibility-
Raspberry Pi 4 Case with TFT comes with precise cutouts, you have seamless access to all ports and interfaces. The Raspberry Pi 4 Case with TFT sleek design not only complements any environment but also allows for easy installation. Elevate your Raspberry Pi experience with this premium case and TFT display.
