Dual Output Adjustable Buck Converter, LM2596 DC 5V-40V to DC 1.25V-35V Power Supply Module 3A Voltage Step Down

• Input Voltage Range: DC 5V-40V
• Output Voltage Range: DC 1.25V-35V
• Output Current: 2.5A at long-term operating, 3A (maximum)

Description:

This is dual-way buck voltage regulator module allows to be inputted 5V-40V and adjustable output 1.25V-35V; its output current is 2.5A and output power is 20W. The voltage regulator board is designed with 2-way output and each of them will not interfere the other and can be adjusted independently. Each way output has a blue indicator for output, users can easily get to know the working status of this power module. It is a step-down converter, to make it work correctly, please keep input voltage higher 1.5V than the output voltage. The power supply module is designed with the large heat sink, strong heat dissipation.

Specification:

• Input Voltage Range: DC 5V-40V
• Output Voltage Range: DC 1.25V-35V
• Output Current: 2.5A at long-term operating, 3A (maximum)
• Output Power: within 20W at long-term operating (just for each way)

Features:

• With heat sink design for strong heat dissipation.
• With output indicator to know the working status of this power module.
• 2-way output design and each of them will not interfere the other and can be adjusted independently.

Package Included:

1 x Dual Output Adjustable Buck Converter, LM2596 DC 5V-40V to DC 1.25V-35V Power Supply Module 3A Voltage Step Down
