TS5823 BosCam 5.8G 200mW 32 Channel FPV Tiny Wireless AV Transmitter for GoPro

The ts5823 transmitter packs 200mw of ultra clean 5.8Ghz power in a micro sized video/audio transmitter. A must have for those looking to save size and weight while still getting good performance. The ts5823 is transmitting a full range of 32 channels. Its perfect for a wide range of aircraft, especially small models and 350 size multi-rotors such as quanum nova, dji phantom, qr x350 and more. This transmitter can easily transmit audio and video from your FPV plane, drone, heli or car. It’s TINY and lightweight, and also doesn’t get too hot. This kit has everything you need to connect it to your portable HD Camera as well.

Specification:

• Item No.: TS5823
• Modulate: Wideband FM Modulate
• Video Format : NTSC/PAL
• Output Impedance:50 Ohm
• Output Power : 23-24dBm
• Channel:32 CH
• Operating Voltage: 7V-24V
• Supply Current : 190mA
• Operating Temperature: -10~85℃
• Video Band Width : 0~8.0 MHz
• Audio Carrier Frequency : 6.5 MHz
• Video Input Level: 0.8~1.2 Vp-p
• Video Input Impedance : 75 Ohm
• Audio Input Level : 0.5~2.0 Vp-p
• Audio Input Impedance : 10K Ohm
• Connector: RP-SMA Male(Inner hole)
• Antenna Connector: RP-SMA Male(Inner hole)

Features:

• Micro sized and light weight
• Perfect for use with small models

Package Included:

1 x TS5823 BosCam 5.8G 200mW 32 Channel FPV Tiny Wireless AV Transmitter for GoPro
