EMAX ES08MA II 12g Mini Metal Gear Analog Servo

This is EMAX ES08MA II 12g mini metal gear analogue servo. This is basically used in science projects, robotic equipment, and RC models also. It has metal gear for a better experience.

Specification:

• Operating Voltage: 4.8V~6.0V
• Operating Current: 200mA/60º
• Operating Speed: 0.12sec/60º at 4.8V; 0.10sec/60º at 6V
• Stall Torque: 1.5/1.8 kg.cm 20.8/24.9 oz.in (4.8V/6v)
• Dead Band: 1-2 uSec
• Gear Material: Metal
• Connector Wire Length: 25 cm
• Connector Type: Futaba/JR compatible

Features:

• Ultra-thin design, with a width of 9mm, this servo is an ideal choice for gliders.
• Made of special engineering plastics, the gear set and case are super tough.
• Noble potentiometer: assuring high accuracy and coherence.
• The dual bearing design maintains low backlash and smoothness of the servo for a long time.

Wire Description:

• RED: VCC (Positive)
• Brown: GND (Negative)
• Orange: PWM (Signal)

Package Included:

1 x EMAX ES08MA II 12g Mini Metal Gear Analog Servo for RC Model
